Ningbo Jiangbei Removable 3 Inch Water Meter
- Brand: Ningbo Jiangbei
- Product Type: Removable Woltman Water Meter
- Nominal Size: 3 Inch (DN80)
- Connection Type: Flanged End
- Meter Type: Dry Dial, Magnetic Transmission
- Measuring Principle: Turbine / Woltman Type
- Accuracy Standard: ISO 4064 / Class B (Class C optional)
- Nominal Flow Rate (Q3): ~40 m³/h
- Maximum Flow Rate (Q4): ~63 m³/h
- Transitional Flow Rate (Q2): ~1.0–2.0 m³/h
- Minimum Flow Rate (Q1): ~0.8–1.5 m³/h
- Measuring Range (R): R80 – R100
- Maximum Working Pressure: 1.0–1.6 MPa (10–16 bar)
- Temperature Class: Cold water up to 30°C (optional hot water up to 90°C)
- Meter Body Material: Ductile Iron / Cast Iron with epoxy coating
- Measuring Element: Removable turbine cartridge unit
- Register Type: Vacuum sealed, anti-fog dial
- Display: Mechanical totalizer with multi-digit counter
- Optional Output: Pulse output / AMR / M-Bus (optional)
- Installation Position: Horizontal pipeline installation
- Flange Standard: ISO PN10 / PN16 drilling
- Typical Applications: Municipal water supply, industrial water distribution, irrigation systems, bulk water measurement, water treatment plants
Out of stock
LKR 39,140.00
Out of stock
-
Pick up from the ROKY Holdings Store
85B, Pagoda Road, Nugegoda, Sri Lanka.
Free
-
Islandwide Delivery
Citypak Courier Service will deliver to the specified address
2-3 Working Days
Payment Methods:
Ningbo Jiangbei 3-Inch Removable Woltman Water Meter is a robust, high-capacity water meter designed for accurate bulk water measurement in municipal, industrial, and water treatment systems. Its removable turbine mechanism, dry-dial magnetic transmission, and durable epoxy-coated body provide reliable performance, easy maintenance, and long-term accuracy in high-flow applications.
| Weight | 50 kg |
|---|
